Scissor Lift SLX

Scissor Lift SLX supports larger, high-brightness projectors up to 12 amps with six lift-capacity models and a UL Listed outlet for reliable power.

Scissor Lift SLX supports larger, brighter video projectors up to 12 amps with ease, offering six models with various lifting capacities. Three sets of scissors ensure lateral and front-to-back projector stability. The extended lift positions streamline projector maintenance during shows and service intervals. Easily set two customizable show positions while still allowing full up and down positions for storage or maintenance. The system retains presets even during power loss. Power projectors seamlessly with a UL-listed receptacle outlet, available in 115V or 240V. Scissor Lift SLX delivers reliable, high-performance support for professional AV installations.

Product Specs

  • Available for 115V and 240V U.S. applications.
  • Lifting capacity varies by size; refer to the Submittal for exact details.
  • Model Options: Choose from six extension-capacity models—SLX10 (10' / 305 cm), SLX14 (14' / 427 cm), SLX17 (17' / 518 cm), SLX21 (21' / 640 cm), SLX24 (24' / 732 cm), and SLX28 (28' / 853 cm).
  • Includes standard built-in control options like RS232 and RS485, with optional RF or IR controls for added flexibility.
  • Smaller projectors can fit within 2’ x 2’ (61 cm x 61 cm) ceiling grid.
  • Offers optional Environmental Airspace Housing to isolate the projector from ceiling airspace.
  • Optional ceiling closure panel in white (standard) or black.
  • Optional ceiling finish kit includes a trim ring and closure panel, order when Airspace Housing is not needed.
  • Offers optional universal-style bracket for easy attachment of different projector models.
  • Factory-installed cables for video and projector control available.
  • Includes wall and service key switch.
  • Lift finish in white (standard) or black.
  • UL Listed Compliance: Entire product certified to meet stringent building code requirements for recessed ceiling installations.

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Skip Navigation Links.

Retail Pricing Table

Display part numbers with 110V or 220V motors.

ModelMax. Lowering
Distance		Retracted HeightLift
Capacity (lbs.)		Net
Weight (lbs.)		Shipping
Weight (lbs.)		Part No.
110 V		U.S. Retail
Price		Dealer Net
Price
SLX1010’7"14 1/8"453133343300250$13394
SLX1414’2"16 3/8"435143353300251$14896
SLX1717’8"18 5/8"418155365300252$17756
SLX2121’3"20 7/8"393170380300253$19184
SLX2424’9"23 1/8"375185395300254$22764
SLX2828’5"25 3/8"350215425300255$25444

Dimensions (WxD) Max Projector Size (WxD) Lowering Distance Unit Weight
Scissor Lift SLX 39 1/2" x 39 1/2" 35" x 35" 120" - 336"
Scissor Lift SLX with large closure 40 9/16" x 46 9/16" 35" x 41" 120" - 336"
